MTS 1-PHASE CONTROL AND ISOLATION TRANSFORMER
P: 100VA IN: 230/400VAC OUT: 230VAC
| Art.No.: | 86348 |
| Alternative product: | 6686348 |
| Weight: | 1.9 kg |
| Country of origin: | CZ |
US
Call for Availability
EU
Available
Description
Single-phase - Control and Isolation Transformers
100 VA
Isolation class T 40/B
Protection IP20
Other voltages on request.
100 VA
Isolation class T 40/B
Protection IP20
Other voltages on request.
Technical Data
Input
| Input voltage | 230/400 V AC |
|---|---|
| Inrush current | 3.53 A (230 V AC); 2 A (400 V AC) |
| Short-circuit current | 4.86 A (230 V AC); 2.8 A (400 V AC) |
| Input current | 0.51 A (230 V AC); 0.29 A (400 V AC) |
| Frequency | 50...60 Hz |
Output
| Output voltage | 230 V AC |
|---|---|
| Output rating | 100 VA |
General data
| Standards | EN 61558-1, EN 61558-2-4, EN 62041 category 0 |
|---|---|
| Mounting method | Long-hole mounting or DIN-rail mountable TH35 (EN 60715) |
| Temperature range | -20...+40 °C (storage temperature -40...+80 °C) |
| Test isolation voltage | 4 kV (prim./sec.) |
| Drill hole Ø | 4.8×8.4 mm |
| Fixing centers a×b×c | 56×56×4.8 mm |
| Dimensions H×W×D | 86×84×98 mm |
Commercial data
| ECLASS-6.0 | 27031302 |
|---|---|
| ECLASS-6.1 | 27031302 |
| ECLASS-7.0 | 27031302 |
| ECLASS-8.0 | 27031302 |
| ECLASS-9.0 | 27031302 |
| ECLASS-10.1 | 27031302 |
| ECLASS-11.1 | 27031302 |
| ECLASS-12.0 | 27031302 |
| ETIM-5.0 | EC002486 |
| customs tariff number | 85043180 |
| EAN | 4048879078481 |
| Packaging unit | 1 |
