MB REDUNDANCY BALANCE
IN: 24VDC/2x20ADC OUT: 24V/20-40ADC
| Art.No.: | 85496 |
| Alternative product: | 85495 |
| Weight: | 0.15 kg |
| Country of origin: | CZ |
US
Available
EU
Available
Description
INPUT: 24 V DC (SELV/PELV)
OUTPUT: max. 2× 20/1× 40 A
low power loss (MOSFET-Technology)
OUTPUT: max. 2× 20/1× 40 A
low power loss (MOSFET-Technology)
Technical Data
Electrical data
| Number of devices parallel connection max. | 2 |
|---|---|
| Parallel connection | yes |
Electrical data | Supply
| Total current max. | 40 A |
|---|
Electrical data | Input
| Input voltage DC | 24 V |
|---|---|
| Input voltage DC min. | 18 V |
| Input voltage DC max. | 30 V |
| Current input AC | 20 A |
| Total current bridge set max. | 40 A |
| Efficiency | 99,5 % |
Electrical data | Output
| Output voltage DC | 24 V |
|---|---|
| Output voltage DC min. | 18 V |
| Output voltage DC max. | 30 V |
| Output voltage adjustable | yes |
| Output current | 26 A |
Diagnostics
| Alarm contact | yes |
|---|---|
| Alarm contact message content | input voltage / load distribution |
| Alarm contact potential free | yes |
Installation | Connection
| Connection | Spring clamp terminals FK |
|---|
Device protection | Electrical
| Invers-polarity protection | yes |
|---|
Mechanical data | Mounting data
| Mounting method | geschnappt |
|---|---|
| Suitable for mounting type | Mounting rail TH35, (EN 60715) |
Environmental characteristics | Climatic
| Operating temperature min. | -25 °C |
|---|---|
| Operating temperature max. | 60 °C |
| Storage temperature min. | -40 °C |
| Storage temperature max. | 85 °C |
| Relative humidity min. (operation) | 5 % |
| Relative humidity max. (operation) | 95 % no condensation |
Commercial data
| ECLASS-6.0 | 27049190 |
|---|---|
| ECLASS-6.1 | 27049002 |
| ECLASS-7.0 | 27049002 |
| ECLASS-8.0 | 27049002 |
| ECLASS-9.0 | 27040701 |
| ECLASS-10.1 | 27040701 |
| ECLASS-11.1 | 27040701 |
| ECLASS-12.0 | 27040701 |
| ETIM-5.0 | EC002540 |
| customs tariff number | 85044095 |
| GTIN | 4048879384698 |
| Packaging unit | 1 |
